Lucent Technologies FT-2000 OC-48 - Example 8 - CONFIGURATION-Retrieve-Circuit-STS3

Craft Interface Terminal Usage
11-50 Issue 8.0 July 2002
Example 8 - CONFIGURATION-Retrieve-Circuit-STS3 11
Releases 5 and Later
The above reports were requested from Worcester in a five node FT-2000 ring.
The ring topology is as follows:
~-> Worcester-MA <-> Salem-NH <-> Concord-MA <-> Chicopee-MA <->
Holyoke-MA <-~
The first report lists the complete circuit in an East to West direction whereas the
second report is in a West to East direction. Each report shows the complete
circuit (path) of slot 1a and lists all cross-connections that make up the circuit.
Delta-1 94-11-29 13:15:15 EST
M Retrieve-Circuit-STS3:1: COMPLD
/* STS-3 Circuit Map Report
==============================================================================
Status: good Cross- Ring
At Node: West Connect East Direction
==============================================================================
Worcester-MA 1a <----- 1e-1
Salem-NH 1w-1 <----- 1e-1 ^
Concord-MA 1w-1 <----- 1e-1 ^
Chicopee-MA 1w-1 <----- 4a ^
Information above is an East to West circuit report.
Information below is a West to East circuit report.
/* STS-3 Circuit Map Report
==============================================================================
Status: good Cross- Ring
At Node: West Connect East Direction
==============================================================================
Worcester-MA 1w-1 -----> 1a
Holyoke-MA 1w-1 -----> 1e-1 ^
Chicopee-MA 3b -----> 1e-1 ^
*/
