365-575-102 Detailed Level Procedure: DLP-503
Issue 8.0, July 2002 Page 3 of 10
NOTE:
Any alarms, other than those shown in the list, may prohibit continuing with the
test until they are cleared.
8. At the CIT, select the appropriate command as follows:
FT-2000 End Terminal: select FAULT-Test-Auto Turnup with All for
Line and DSX for Mode.
FT-2000 Add/Drop-Rings Terminal: select FAULT-Test-Auto Tur-
nup-DSX with All for Slot.
Response: Execution in progress (one dot appears about every
2 seconds).
NOTE:
A"g" is for good or successful test. A "-" is for not tested. An "F" is for failed or
unsuccessful test.
9. Does report indicate "g" for good or "-" for not tested for each entry?
(See Figure 1 for a service line only in a point-to-point network.)
(See Figure 2 for a service line and a protection line in a point-to-point network.)
(See Figure 3 for a shared service/protection line in a ring network.)
If YES, then continue with Step 10.
If NO, then refer problem to the group that installed the equipment.
FT-2000 Point-to-Point Network FT-2000 Ring Network
Source
Description
Source
DescriptionAddress Address
line-1 incoming OC-48 LOS line-1e incoming OC-48 LOS
line-p incoming OC-48 LOS line-1w incoming OC-48 LOS
system APS channel failure system ring incomplete/open
system incoming DCC failure (only if enabled) system DS-NE not reachable
line-1 site provisioning conflict system squelch map conflict
line-p site provisioning conflict line-1e incoming DCC failure
rcvr-1 receiver parameter-out-of-range line-1w incoming DCC failure
rcvr-p receiver parameter-out-of-range
