Craft Interface Terminal Usage
Issue 8.0 July 2002
11-79
Example 22 - SECURITY-Retrieve-Network Element 11
Releases 6 and Later (Use the SECURITY category.)
The above report shows the provisioned parameters and values for an individual
network element (NE). The retrieved parameter values include target ID (TID),
directory services NE (DSNE), the X.25 packet size, the site address (SADD), the
alarm group, and the alarm gateway network element (AGNE).
TID - Shows the unique identification of the node.
Directory
Service NE
- Shows whether or not this network element is serving as the
Directory Server node in the ring network. Only one node is
provisioned as the DS-NE in the ring network.
X25 Packet
Size
- ShowstheX.25packetsizetobeusedforaTL1sessiontothis
network element. The original value (size) is 256 but may be 128.
Site Address
(SADD)
- Shows the confirmed F-byte address (site address) of the FT-2000
network element as reported on both the East and West lines for
Release 4.0 and later. The site address is derived from the
autoprovisioning function based on an OC-48 line section. If a
question mark (?) appears as part of the value, then auto
provisioning has not been completed or it failed (for example, a
removed or failed LNCTL).
Alarm Group - Shows a value from zero to 255 where the value represents a
SONET maintenance sub-branch (SMSB) alarm group of network
elements that exchange alarm information. A zero (0) means no
remote alarm information is exchanged.
Alarm
Gateway NE
- Shows whether or not the local NE will serve the other members of
its alarm group as an alarm gateway network element (AGNE).
TSA
Granularity
- Release 7 and later. Shows whether or not the local NE is
operating in an STS3 or STS1 granular mode (dependent on
TRMTR and RCVR).
/* FT-2000 System Provisioning Report
=====================================================================
Parameter Value
=====================================================================
TID system_name234567892
Directory Service NE yes
X25 Packet Size 256
Site Address (SADD) site-1e-0
site-1w-4
Alarm Group 247
Alarm Gateway NE yes
TSA Granularity STS1
*/
