Lucent Technologies FT-2000 OC-48 - Example 32 - PERFORMANCE-Retrieve-PM-STS1

Craft Interface Terminal Usage
Issue 8.0 July 2002
11-103
Example 32 - PERFORMANCE-Retrieve-PM-STS1 11
Releases 4 and Later
The above report (can be a multiple page report) shows the current STS-1 path
performance-monitoring data (day and quarter-hour) for an electrical low-speed
signal on line 1, slot 1, ports 1, 2, and 3 received from the OC-48 line. Data is
collected at the near end (B3) and at the far end (FEBE). When a greater than
sign (">") is displayed, it means the violations are greater than the maximum value
for the parameter. When a question mark ("?") is displayed, it means corrupted
data or an incomplete time cycle for that parameter. When a hyphen ("-") is
displayed, it means the data is unavailable, such as any port in the NMON or
AUTO state. An asterisk (*) is displayed whenever the threshold-crossing alert
(TCA) is reached. This report is not available at the repeater site.
Delta-1 93-07-15 13:15:15 EST
M Retrieve-Performance Monitoring-STS1:1e-All: COMPLD
/* STS-1 Path Performance Monitoring Status Report
Bin Start Time: quarter hour registers at yy-mm-dd hh:mm:ss
day registers at yy-mm-dd hh:mm:ss
========================================================================
Start ------- Path (B3) ------ ----- Far End (FEBE)------
Address Time CV-P ES-P SES-P UAS-P CV-F ES-F SES-F UAS-F
========================================================================
sts1-1e-1-1 Today 3449* 1 0 0 5 1 0 0
-----------------------------------------------------------
09:00 5 1 0 0 5 1 0 0
========================================================================
sts1-1e-1-2 Today 8912345> 25 2 0 12345 25 2 0
.
.
.
========================================================================
sts1-1e-16-3 Today 12345? 25? 2? 0? 12345? 25? 2? 0?
-----------------------------------------------------------
09:00 0?0?0?0? 0?0?0?0?
*/
;
Information below is for Release 4.0 and Release 4.1
/* STS-1 Path Performance Monitoring Status Report
Last initialized: quarter hour registers at yy-mm-dd hh:mm:ss
day registers at yy-mm-dd hh:mm:ss
========================================================================
Start ------- Path (B3) ------ ----- Far End (FEBE)------
Address Time CV ES SES UAS CV ES SES UAS
========================================================================
