Cable Access 10
■ Rear only required for adding shelves or upgrading FT-2000 terminal bays
■ Front for all customer access
■ Connectorized cabling with commercially available connectors
Figure 10-2 depicts various “Inter-office” options for connecting two NEs via
coaxial cable.
Figure 10-2. Common Coaxial Cable Interoffice Cross-Connect
Options for DS-3 and STS-1E
Notes:
1. KS-19224 cable used in early installations, 300’ maximum NE-
NE, 27’ maximum DSX patch.
2. 728A cable used in early installations, same loss as 734-type.
3. 734A same loss as 734D, must be soldered.
4. Use 9824AG LBO on FT outputs when required.
Loss equivalent to 225’ 734 or 125’ 735 cable(~3 dB).
5. Lucent cables may be ordered from ED-8C900-20.
6. Lucent installers use TK-604 to terminate cables.
7. Refer to 365-301-130 Planning/Engineering/
Installation/Operation Guide.
XX
500’ 735A
900’ 734D
250’ 735A NE - DSX
250’ 735A DSX - NE
735 PC
35’ Max
X
X
735 PC
35’ Max
450’ 734D NE - DSX
450’ 734D DSX -NE
Network
Element
X
X
735 PC
35’ Max
13’ 735A
450’ 734D NE - DSX
250’ 735A DSX - NE
XX
735 PC
35’ Max
450’ 734D NE - DSX
450’ 734D DSX -NE
13’ 735A 13’ 735A
Splice Splice
11.58 dB
LBO
0-125’ 735A
X
LBO
0-225’ 734D
X
Splice
13’ 735A
Network
Element
