Lucent Technologies FT-2000 OC-48 - OC-48 Lightwave System and Wavelength Division Multiplexing Systems Loss Budgets; OC-48 Lightwave System and Wavelength Division Multiplexing Systems

Technical Specifications
10-12 Issue 8.0 July 2002
FT-2000 OC-48 Lightwave System and
Wavelength Division Multiplexing Systems 10
The FT-2000 OC-48 Lightwave System is also designed to meet the OC-48 loss budget
specifications shown in Table 10-8 when operating with wavelength division multiplexing
(WDM) systems.
*Transmit and receive powers are referenced to points S and R as shown in Figure 10-1.
†These values include transmitter/receiver connectors @ 0.7 dB each (worst case) and the system margins.
‡ The receiver sensitivity and maximum received power values are measured at a BER of 1x10
-10
.
§ The 1.5 µm Standard Performance optics is dispersion limited to 92 kilometers.
¶ These values assume that the maximum received power limitations are not exceeded.
Table 10-8. FT-2000 OC-48 Lightwave System and Wavelength Division Multiplexing Systems
Loss Budgets
OC48TRMTR(A/D1.5LBA,W1andW2)
Parameter OC48TRMTR(A/DSTS11.5LBA,W1andW2)
Maximum Transmitter Power (P
Tmax
)* 3.3 dBm
Minimum Transmitter Power (P
Tmin
)† 0.0 dBm
Maximum Received Power (P
Rmax
)‡ −11.0 dBm
Receiver Sensitivity (P
Rmin
)†‡ −27.0 dBm
Minimum System Gain (S-R) 27.0 dB
MXR/DMXR Loss 4.5 dB
Optical Path Penalty (P
O
)2.0dB
Maximum Loss Budget§ 20.5 dB
Minimum Loss Budget¶ 10.0 dB
Optical Dispersion 2520 ps/nm
