Page #852 background imageLoading...
Page #852 background image
Craft Interface Terminal Usage
11-144 Issue 8.0 July 2002
Example 48 - CONFIGURATION-Retrieve-Synchronization 11
Releases 3 and Later (Use the CONFIGURATION category.)
The above report shows the provisioned synchronization parameters of the
FT-2000 ring network. Additional synchronization information is contained in
Volume I, Section 5, "Control, Transmission, and Synchronization Interfaces."
Parameter -
Provisioned Mode
shows the synchronization mode that was
provisioned at the FT-2000 add/drop-rings terminal.
Operating Mode (East/West)
shows the current synchronization
mode being used in the FT-2000 network.
TG1/TG2 Clock Range Status
shows the current percentage that the
frequency is off of the center frequency. The lower the percentage,
the closer the frequency is to the center frequency. The deviation
limits in ppm are ±100 but the allowable range is ±110.
Primary/Secondary DS1 In/Out Format
shows the value that was
provisioned, either D4 super frame format (SF) or extended super
frame (ESF).
Primary/Secondary DS1 In Line Code
shows the provision value,
either alternate mark inversion (AMI) or bipolar with 8 zeros
substitution (B8ZS).
DS1 Out 1/Out 2 Equalizations
shows the equalizer setting of the
DS1 external reference output 1/output 2. The value is a percentage
of the maximum cable length; for example, 100 (%) equates to a
maximum of 660 feet of 600-type cable.
Value - The values are discussed with the parameter.
Delta-1 93-01-19 23:15:15 EST
M Retrieve-Synchronization: COMPLD
/* Synchronization Report
=============================================================
Parameter Value
=============================================================
Provisioned Mode Free Running
Operational Mode (East) Free Running
Operational Mode (West) Free Running
TG1 Clock Range Status 0%
TG2 Clock Range Status -2%
Primary DS1 In/Out Format SF
Secondary DS1 In/Out Format SF
Primary DS1 In Line Code AMI
Secondary DS1 In Line Code AMI
DS1 Out 1 Equalization 20%
DS1 Out 2 Equalization 20%
*/
;
