Craft Interface Terminal Usage
Issue 8.0 July 2002
11-145
Release 2 (Use the CONFIGURATION category.)
The above report shows the provisioned synchronization parameters of the
FT-2000 end terminal.
Parameter -
Provisioned Mode
shows the synchronization mode that was
provisioned for the FT-2000 end terminal.
Operational Mode
shows the current synchronization mode being
used in the FT-2000 System.
TG1/TG2 Clock Range Status
shows the current percentage that
the frequency is off the center frequency. The lower the
percentage, the closer the frequency is to the center frequency.
The deviation limits in ppm are ±100 but the allowable range is
±110.
Primary/Secondary DS1 In Format
shows the value that was
provisioned, either super frame format (D4) or extended super
frame.
Primary/Secondary DS1 In Line Code
shows the provision value,
either alternate mark inversion or bipolar with 8 zeros
substitution.
DS1 Out 1/Out 2 Equalizations
shows the equalizer setting of the
DS1 external reference output 1/output 2. The value is a
percentage of the maximum cable length; for example, 100 (%)
equates to a maximum of 660 feet of 600-type cable.
Value - The values are discussed with the parameter.
Lucent Technologies-FT-2000 96-07-19 23:15:15 EST
M Retrieve-Synchronization: COMPLD
/* Synchronization Report
=============================================================
Parameter Value
=============================================================
Provisioned Mode Phase Locked
Operational Mode Phase Locked - Secondary DS1
TG1 Clock Range Status 10%
TG2 Clock Range Status -5%
Primary DS1 In Format ESF
Secondary DS1 In Format SF
Primary DS1 In Line Code B8ZS
Secondary DS1 In Line Code AMI
DS1 Out 1 Equalization 20%
DS1 Out 2 Equalization 20%
*/
;
