Craft Interface Terminal Usage
Issue 8.0 July 2002
11-47
Example 7 - CONFIGURATION-Retrieve-Circuit-STS1 11
Releases 7 and Later
For these reports, the ring topology is:
â–  West to East from Worcester-MA
â–  West-East between Worcester and Salem-NH
â–  West-East between Salem and Concord-MA
â–  West-East between Concord and Chicopee-MA.
The above report was requested from Worcester and lists the complete circuit
from Chicopee to Worcester in the West to East direction.
The following report was requested from Worcester and lists the complete circuit
from Chicopee to Worcester in the West to East direction:
Delta-1 94-11-29 13:15:15 EST
M Retrieve-Circuit-STS1:1: COMPLD
/* STS-1 Circuit Map Report
==============================================================================
Status: good Source Destination Ring Primary
Ring Node AID AID Direction State Audit
==============================================================================
Worcester-MA 1e-1-3 ls-1a-1 y
Salem-NH 1e-1-3 1w-1-3 East to West y
Concord-MA 1e-1-3 1w-1-3 East to West y
Chicopee-MA ls-4a-2 1w-1-3 East to West y
*/
/* STS-1 Circuit Map Report
==============================================================================
Status: audit disabled Source Destination Ring Primary
Ring Node AID AID Direction State Audit
==============================================================================
12345678901234567890 123456789 123456789 12345678901 1234 12
Worcester-MA 1e-1-3 ls-1a-1 NO
Salem-NH 1e-1-3 1w-1-3 East to West y
Concord-MA 1e-1-3 1w-1-3 East to West y
Chicopee-MA ls-4a-2 1w-1-3 East to West y
*/
