Lucent Technologies FT-2000 OC-48 - TL1;X.25 Interface - LAPB Link Layer Parameters; TL1;X.25 Interface - X.25 Packet Layer Parameters

Technical Specifications
Issue 8.0 July 2002
10-45
At the link layer, the FT-2000 OC-48 Lightwave System uses the standard link
access procedure B (LAPB) protocol with the parameters listed in Table 10-21.
The FT-2000 OC-48 Lightwave System uses synchronous, full duplex, continuous
carrier communication. Data rates of 1200, 2400, 4800, 9600, and 19200 are
supported.
Table 10-20. TL1/X.25 Interface — X.25 Packet Layer Parameters
Parameter Value
Packet Size 256 bytes
Window Size 2 packets
D bit support No
M bit support Yes
Q bit support No
Table 10-21. TL1/X.25 Interface — LAPB Link Layer Parameters
Parameter Value
Maximum Frame Size 2104 bits
Modulo 8
Window Size 7 frames
n2 6 retries
T1 3 seconds
T3 not supported
