Platform Descriptions
3-42 Issue 8.0 July 2002
The Repeater Shelf — System Controller has two front covers. One covers the
interconnection panel and the other covers the circuit packs. Openings are
provided in the top cover that allow the user panel to show through and provide
access to the CIT port. The covers are hinged and can be easily removed for
maintenance access. Figure 3-23 shows the Repeater Shelf — System Controller
with covers for the FT-2000 OC-48 Repeater Bay. Figure 3-24 shows the
Repeater Shelf — System Controller with covers for the miscellaneously mounted
FT-2000 OC-48 Repeater Shelf.
Figure 3-23. Repeater Shelf — System Controller with Covers
(FT-2000 OC-48 Repeater Bay)
Repeater Shelf - System Controller
