Lucent Technologies FT-2000 OC-48 - OC-48 Lightwave System with Wavelength Division Multiplexing Systems and FT-LBA Loss Budgets; OC-48 Lightwave System with Wavelength Division Multiplexing and FT-LBA Systems

Technical Specifications
Issue 8.0 July 2002
10-13
FT-2000 OC-48 Lightwave System with
Wavelength Division Multiplexing and FT-LBA
Systems 10
The FT-2000 OC-48 Lightwave System is also designed to meet the OC-48 loss budget
specifications shown in Table 10-9 when operating with wavelength division multiplexing
(WDM) systems and the FT-LBA (+16 dBm system).
* Transmit and receive powers are referenced to points S and R as shown in Figure 10-1.
† These values include transmitter/receiver connectors @ 0.7 dB each (worst case) and the system margins.
‡ The receiver sensitivity and maximum received power values are measured at a BER of 1x10
-10
.
§ The 1.5 µm Standard Performance optics is dispersion limited to 92 kilometers.
¶ These values assume that the maximum received power limitations are not exceeded.
Table 10-9. FT-2000 OC-48 Lightwave System with Wavelength Division Multiplexing
Systems and FT-LBA Loss Budgets
OC48TRMTR(A/D1.5LBA,W1andW2)
Parameter OC48TRMTR(A/DSTS11.5LBA,W1andW2)
Maximum Transmitter Power (P
Tmax
)* 17.0 dBm
Minimum Transmitter Power (P
Tmin
)† 14.0 dBm
Minimum Transmitter Power per Channel 11.0 dBm
Maximum Received Power (P
Rmax
)‡ −11.0 dBm
Receiver Sensitivity (P
Rmin
)†‡ −27.0 dBm
MinimumSystemGain(S-R) 38.0dB
FT-LBA Asymmetric Gain Penalty 2.5 dB
DMXR Loss 2.5 dB
Optical Path Penalty (P
O
)2.0dB
Maximum Loss Budget§ 31.0 dB
Minimum Loss Budget¶ 10.0 dB
Optical Dispersion 2520 ps/nm
