365-575-102 DetailedLevelProcedure:
Issue 8.0, July 2002 Page 1 of 2
DLP-505
Perform Provisioning
1.
NOTE:
The FT-2000 does not have any manual or switch-settable options on its
circuit packs.
NOTE:
Information about FT-2000 provisioning is provided in Section 8,
"Administration and Provisioning," of this manual. Other helpful information
is the CIT tutorial and commands tables (by release), which are located in
Section 11 of this manual, and the job aids on provisioning as follows:
• 365-575-121,
FT-2000 OC-48 Repeater Bay/Shelf Provisioning Job Aid
(Releases 2, 4, and 6)
• 365-575-122,
FT-2000 OC-48 Add/Drop-Rings Terminal Provisioning Job
Aid (Releases 3, 4, 5, 6, and 7)
• 365-575-123,
Threshold-Crossing Alert (TCA) Parameters Provisioning
Job Aid (Release 4 and Later)
• 365-575-124,
FT-2000 Cross-Connections Job Aid (Releases 3, 4, 5, 6,
and 7)
At the CIT, select CONFIGURATION, PERFORMANCE, FAULT, or SECURITY
category and the appropriate inputs [verb and modifier(s)].
NOTE:
Table 11-9 lists the reports and how to obtain them. For example, the System
Alarm Attributes Report is obtained by using CONFIGURATION-Retrieve-
Attribute-Alarm. Another example is the Synchronization Report that is
obtained by using CONFIGURATION-Retrieve-Synchronization.
Did the appropriate report show that provisioning has been done?
If YES, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then (1) refer the problem to the group that did the original provisioning, and/or
(2) compare the report with the original work order and correct the provisioning
discrepancy. Provisioning job aids are available; see Step 1 for the specific
equipment references.
