Lucent Technologies FT-2000 OC-48 User Manual

Control, Transmission, and Synchronization Interfaces
Issue 8.0 July 2002
5-29
■ One node provisioned free running; all other nodes provisioned Line
Timed: Refer to (Figure 5-17).
Figure 5-17. Example of a Ring Application with One Node
Provisioned Free Running and All Other Nodes
Provisioned Line Timed (Without Timing Drops)
NOTE:
If synchronous (EC-1, OC-3, IS-3 and/or OC-12) low speed
interfaces are to be added to nodes of an asynchronous application,
one node should be provisioned externally timed (phase locked in
releases prior to Release 5), and all other nodes should be
provisioned "through timed," "line timed," or "externally timed."
FT-2000
FT-2000
FT-2000
DS3
DS3
DS3
DS3
Free Running
FT-2000
Line Timed
Line Timed
Line Timed
