Technical Specifications
10-14 Issue 8.0 July 2002
Transmission Distances 10
FT-2000 OC-48 Lightwave System without
Optical Amplifiers 10
Table 10-10 shows the transmission distances of the FT-2000 OC-48 Lightwave System
without optical amplifiers (for example, the FT-Lightwave Booster Amplifier).
Notes :
1. Standard fiber assumes the following fiber loss (including splice loss) with a dispersion limit of 18 psec/nm
per kilometer:
1.3 µm — 0.45 dB/km
1.5 µm — 0.25 dB/km.
2. Low loss fiber assumes the following fiber loss (including splice loss) with a dispersion limit of 18 psec/nm
per kilometer:
1.3 µm — 0.375 dB/km
1.5 µm — 0.22 dB/km.
3. Dispersion-shifted fiber assumes a 0.25 dB/km loss at 1.5 µm.
4. Only 1.5 µm transmitters will work with dispersion-shifted fiber.
* The dispersion limit applies only to the OC48 TRMTR (A/D 1.5 STD) circuit pack using standard fiber.
The limit is 1800 psec/nm or 100 km.
Table 10-10. Transmission Distances without Optical Amplifiers
Circuit Pack Loss Budget
Standard
Fiber (Note 1)
Low Loss
Fiber (Note 2)
Dispersion-Shifted
Fiber (Note 3) (Note 4)
OC48 TRMTR (A/D 1.3 STD) 24 dB 53 km 64 km —
OC48 TRMTR (A/D STS1 1.3
STD)
33 miles 40 miles
OC48 TRMTR (A/D 1.3 HI
PERF)
27 dB 60 km 72 km —
OC48 TRMTR (A/D STS1 1.3 HI
PERF)
37 miles 45 miles
OC48 TRMTR (A/D 1.5 STD)* 23 dB (SF) 92 km 105 km 96 km
OC48 TRMTR (A/D STS1 1.5
STD)
24 dB (DSF) 57 miles 65 miles 60 miles
OC3(1.3STD) 23dB 51km 61km —
32 miles 38 miles
OC12 (1.3 STD) 23 dB 51 km 61 km —
32 miles 38 miles
OC48 739E_ TRMTR (A/D 1.5
STD)
23 dB
OC48 739G_ TRMTR (A/D 1.5
STD)
23 dB
OC48 739H_ TRMTR (A/D 1.5
STD)
23 dB
