Example 50 - CONFIGURATION - Retrieve-Timeslot-STS1 11
Releases 7 and Later
This command retrieves a Tributary Map report, organized by node, for all nodes
in a ring. The report shows all cross-connections on a single user-specified time
slot throughout the entire ring, indicating parts of the ring available for new
circuits.
/* STS-1 Tributary Map Circuit Report
==============================================================================
Source Source Destination Destination Primary
Ring Node TID AID AID TID State
==============================================================================
Worcester-MA
Quabbin-MA 1w-1-2 ls-1a-3 Worcester-MA
Worcester-MA ls-1a-1 1e-1-2 Salem-NH
Chicopee-MA 1e-1-2 ls-1b-3 Worcester-MA
Worcester-MA 1w-1-2 Worcester-MA
------------------------------------------------------------------------------
Salem-NH
Worcester-MA 1w-1-2 ls-7a-2 Salem-NH
Salem-NH ls-2a-2 1e-1-2 Chicopee-MA ACT
Salem-NH ls-2b-2 1e-1-2 Salem-NH STBY
Chicopee-MA 1e-1-2 1w-1-2 Worcester-MA
------------------------------------------------------------------------------
Concord-MA
Salem-NH 1w-1-2 1e-1-2 Chicopee-MA
Chicopee-MA 1e-1-2 1w-1-2 Worcester-MA
------------------------------------------------------------------------------
Chicopee-MA
Salem-NH 1w-1-2 ls-4a-2 Chicopee-MA
Chicopee-MA 1e-1-2 Chicopee-MA
Chicopee-MA ls-4a-1 1w-1-2 Worcester-MA
Chicopee-MA 1e-1-2
Chicopee-MA
------------------------------------------------------------------------------
Holyoke-MA
Holyoke-MA 1w-1-2 Holyoke-MA
Holyoke-MA 1e-1-2 Holyoke-MA
Holyoke-MA 1w-1-2 Holyoke-MA
Holyoke-MA 1e-1-2 Holyoke-MA
------------------------------------------------------------------------------
Quabbin-MA
Quabbin-MA ls-6a-1 1e-1-2 Worcester-MA
Quabbin-MA 1w-1-2 Quabbin-MA
Quabbin-MA 1w-1-2 Quabbin-MA
Quabbin-MA 1e-1-2 Quabbin-MA
*/
