Lucent Technologies FT-2000 OC-48

To Next Page

To Previous Page

Tab le of Conten ts

Issue 8.0 July 2002 6-i

Operations Interfaces

Overview 6-1

Craft Interface Terminal 6-1

■ General 6-1

■ PC with FT-2000 CIT-PC Software 6-2

■ PC with CPro-2000 Software 6-5

■ ASCII-Based Terminal 6-7

■ Local Access Through the CIT (DCE) Port 6-8

■ Dial-Up Access Using a Modem Through the CIT

(DTE) Port 6-8

■ Remote Access Using the OC-48 Data

Communications Channel (DCC) 6-10

■ Remote Access Using the OC-48 Section Orderwire 6-10

■ Remote Access Using the OC-3/OC-12 Data

Communications Channel (DCC) 6-12

User Panel 6-13

Filter Panel 6-17

Office Alarms Interface 6-19

Parallel Telemetry Interface 6-20

User-Settable Miscellaneous Discrete Interface 6-20

Serial Telemetry Interface 6-22

Message-Based Operations System Interface 6-23

Orderwire Interface 6-30
