Craft Interface Terminal Usage
11-128 Issue 8.0 July 2002
Example 41 - CONFIGURATION-Retrieve-Protection-Line 11
Releases 4 and Later (Use the CONFIGURATION category)
The first report shows the provisioned protection switching information of the
FT-2000 add/drop-rings terminal. The second report shows a Release 4.0 1x1
end terminal report.
Operating
Mode
- Shows the add/drop-rings terminal configuration and whether
protection switching is unidirectional or bidirectional.
Wait To
Restore
- Shows the time (up to 12 minutes after a trouble clears)
before breaking automatic high-speed, low-speed, and
synchronization reference protection switches. A value of
zero minutes will disable this parameter.
Provisioned
Mode
- For 1x1 end terminal only. Shows the current provisioned
protection switching configuration and whether protection
switching is unidirectional or bidirectional.
Restoration
Protection
Access
- For 1x1 end terminal only. Shows the parameter value
(either yes or no) if the FT-2000 terminal is provisioned for
restoration protection access.
Delta-1 93-01-19 23:15:15 EST
M Retrieve-Protection-Line: COMPLD
/* Network Element Protection Switching Provisioning Report
=============================================================
Parameter Value
=============================================================
Operating Mode 2 fiber ring bi-directional
Wait To Restore 0 (disabled)
*/
Information below is a Release 4.0 1x1 end terminal example
Operating Mode 1x1 bi-directional
Provisional Mode 1x1 bi-directional
Wait To Restore 3 minutes
Restoration Protection Access no
*/
;
