Lucent Technologies FT-2000 OC-48 - Example 46 - CONFIGURATION-Retrieve-Squelch Map-STS3

Craft Interface Terminal Usage
11-136 Issue 8.0 July 2002
Example 46 - CONFIGURATION-Retrieve-Squelch Map-STS3 11
(Release 6 and earlier)
The above report shows the STS-3 level squelch map that exists in the FT-2000
add/drop-rings terminal. Examples of cross-connections and additional
information are provided in Volume I, Section 8. The fields of the report are
described below:
Source/
Destination
- Shows the target identifier (TID) and may be either the
source node or the destination node. A dash is shown
when a tributary is not cross-connected. A question mark
(?) is shown when a tributary is cross-connected to a null
(no) source/destination TID. An asterisk is shown for
invalid TID/NID pairs.
NID - Shows the node ID from 0 to 15 of the squelch map. A
dash is shown when the tributary is not cross-connected.
A question mark is shown when a tributary is
cross-connected to an incorrect source or destination TID.
West - Shows the STS-3 tributary address (line direction and
tributary).
East - Shows the STS-3 tributary address (line direction and
tributary).
Delta-1 94-06-15 23:15:15 EST
M Retrieve-Squelch Map:STS3:All: COMPLD
/* STS-3 Squelch Map Report
==============================================================================
Source/Destination NID West East NID Destination/Source
==============================================================================
Worcester-MA 2 --> 1w-1 1e-1 --> 1 *Chicopee-MA
Worcester-MA 2 <-- 1w-1 1e-1 <-- 15 Springfield-MA
- 1w-2 1e-2 -
West-Ossipee-NH 4 <-- 1w-3 1e-3 <-- 3 Rutland-VT
West-Ossipee-NH 4 --> 1w-3 1e-3 --> 3 Rutland-VT
Boscawen-NH* ? --> 1w-4 1e-4 --> 5 Keene-NH
- <-- 1w-4 1e-4 <-- 5 Keene-NH
- 1w-5 1e-5 -
-1w-61e-6-
-1w-71e-7-
-1w-81e-8-
-1w-91e-9-
- 1w-10 1e-10 -
- 1w-11 1e-11 -
- 1w-12 1e-12 -
- 1w-13 1e-13 -
- 1w-14 1e-14 -
- 1w-15 1e-15 -
- 1w-16 1e-16 -
*/
;
