DLP-502: Detailed Level Procedure 365-575-102
Page2of4 Issue8.0,July2002
4. At the CIT, select FAULT-Test-Auto Turnup with Mode: Local and All
for the lines. This test can take up to 10 minutes.
Response: Execution in progress (one dot appears about every
2 seconds).
5. A "good" is for a successful test. A "-" is for not equipped, therefore not
tested. A "FAIL" is for an unsuccessful test.
Does the report indicate "good"or"-" for each entry? SeeFigure3foran
FT-2000 repeater bay/shelf example with a service line and a protection line.
If YES, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then refer the problem to the group that installed the equipment.
6. At the CIT, select FAULT-Test-Auto Turnup-Local.IfAuto Turnup
does not appear as a menu item, log out of the CIT by pressing F5 key and
answer "yes" to the confirmation message. You must log into the CIT in the
expert mode by entering cit expert at the DOS prompt. This test can take
up to 10 minutes.
Response: Execution in progress (one dot appears about every
7.
NOTE:
A"g" is for good or successful test. A "-" is for not equipped, therefore not
tested. An "F" is for failed or unsuccessful test.
Does the report indicate "\f5g\f1" for good or "\f5-\f1" for not tested for each
entry? See Figure 4 for an FT-2000 add/drop-rings terminal example with a
fiber sharing service and protection.
If YES, then STOP! YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then refer the problem to the group that installed the equipment.
