Craft Interface Terminal Usage
Issue 8.0 July 2002
11-93
Example 27 - PERFORMANCE-Retrieve-PM-Line 11
Releases 4 and Later (Use the PERFORMANCE category.)
The above report shows the current performance-monitoring data for the OC-48
line(s). When a greater than sign (">") is displayed, it means the violations are
greater than the maximum value for the parameter (overflow). When a question
mark ("?") is displayed, it means corrupted data or incomplete time cycle for that
parameter. An asterisk is displayed whenever the threshold-crossing alert (TCA)
is reached. This report is not available at the repeater site.
Delta-1 94-06-15 13:15:15 EST
M Retrieve-Performance Monitoring-Line-OC48:1e: COMPLD
/* OC-48 Line Performance Monitoring Status Report
Bin Start Time: quarter hour registers at yy-mm-dd hh:mm:ss
day registers at yy-mm-dd hh:mm:ss
=============================================================================
Start ------------ OC-48 Line (B2) ------------
Address Time CV-L ES-L SES-L UAS-L PSC
=============================================================================
line-1e Today 133456? 0? 0? 0? 0?
03-20 13110
03-19 13110
03-18 00101
---------------------------------------------------------------------
09:00 10000
08:45 30050
08:30 8 8 3 900 0
08:15 5315000> 115* 0 0 0
*/
;
Information below is for Release 4.0 and Release 4.1
M Retrieve-Performance Monitoring-Line-OC48:All: COMPLD
/* OC-48 Line Performance Monitoring Status Report
Last initialized: quarter hour registers at 93-01-15 13:15:00
day registers at yy-mm-dd hh:mm:ss
=====================================================================
Start ------------ OC-48 Line (B2) ------------
Address Time CV ES SES UAS PSC
=====================================================================
