Example 51 - CONFIGURATION-Retrieve-Timeslot-STS3 11
(Releases 5 and Later)
The above report shows the STS-1 level cross-connections making up the
specified STS-3 tributary that exists in the FT-2000 ring (West-to-East sequence).
Examples of cross-connections and additional information are provided in
Volume I, Section 8.
Delta-1 94-06-15 23:15:15 EST
M Retrieve-Timeslot:STS3:1: COMPLD
/* STS-3 Tributary Map Report
==============================================================================
At Node TID West Cross-connection East TID
==============================================================================
Worcester-MA
Quabbin-MA 1w-1 ---> 1a 1a ---> 1e-1 Salem-NH
1b <--- 1e-1 Chicopee-MA
------------------------------------------------------------------------------
Salem-NH
Worcester-MA 1w-1---> 2b 4a ---> 1e-1 Chicopee-MA
1w-1 <--- 2b 1e-1
Worcester-MA 1w-1 <................ 1e-1 Chicopee-MA
------------------------------------------------------------------------------
Concord-MA
Salem-NH 1w-1 -----------------> 1e-1 Chicopee-MA
Worcester-MA 1w-1 <---------------- 1e-1 Chicopee-MA
------------------------------------------------------------------------------
Chicopee-MA
Salem-NH 1w-1---> 4a 1e-1
Worcester-MA 1w-1<--- 4a
------------------------------------------------------------------------------
Holyoke-MA
1w-1 1e-1
------------------------------------------------------------------------------
Quabbin-MA
1w-1 6a---> 1e-1 Worcester-MA
*/
