Technical Specifications
10-46 Issue 8.0 July 2002
The EIA-232D interface is configured as DTE, using the pins listed in Table 10-22.
Table 10-22. TL1/X.25 Interface — EIA-232D Pin Connections
Pin Description
1 Protective Ground (Shield)
2 Transmitted Data
3 Received Data
4 Request to Send (RTS)
*
* DTR and RTS are always on when FT-2000 is powered.
5 Clear to Send (CTS)
â€
†FT-2000 will only transmit data via X.25 when CTS is on.
6 DCE Ready
7 Signal Ground
8 Received Line Signal Detector
15 Transmit Clock (TC)
17 Receive Clock (RC)
20 Data Terminal Ready (DTR)*
