Lucent Technologies FT-2000 OC-48 - Example 45 - CONFIGURATION-Retrieve-Squelch Map-STS1

Craft Interface Terminal Usage
Issue 8.0 July 2002
11-135
Example 45 - CONFIGURATION-Retrieve-Squelch Map-STS1 11
(Release 6 and earlier)
The above report shows the STS-1 level squelch map that exists in the FT-2000
add/drop-rings terminal. Examples of cross-connections and additional
information are provided in Volume I, Section 8.
Source/
Destination
- Shows the target identifier (TID) and may be either the
source node or the destination node. A flag (* or a
blank) is added to the TID to indicate a legal
combination (TID/NID) in the DIB.
NID - Shows the node ID from 0 to 15 of the squelch map.
West - Shows the STS-1 tributary address for a valid entry and
shows the STS-3 tributary address for a null (no) entry.
East - Shows the STS-1 tributary address for a valid entry and
shows the STS-3 tributary address for a null (no) entry.
Delta-1 94-06-15 23:15:15 EST
M Retrieve-Squelch Map:STS1:All: COMPLD
/* STS-1 Squelch Map Report
==============================================================================
Source/Destination NID West East NID Destination/Source
==============================================================================
Worcester-MA 2 --> lw-1-1 1e-1-1 --> 1 *Chicopee-MA
Worcester-MA 2 <-- 1w-1-1 1e-1-1 <-- 15 Springfield-MA
Worcester-MA 2 --> 1w-1-2 1e-1-2 --> 1 *Chicopee-MA
Worcester-MA 2 <-- 1w-1-2 1e-1-2 <-- 15 Springfield-MA
Worcester-MA 2 --> 1w-1-3 1e-1-3 --> 1 *Chicopee-MA
Worcester-MA 2 <-- 1w-1-3 1e-1-3 <-- 1 *Chicopee-MA
- 1w-2 1e-2 -
West-Ossipee-NH 4 --> 1w-3-1 1e-3-1 --> 3 Rutland-VT
West-Ossipee-NH 4 <-- 1w-3-1 1e-3-1 <-- 3 Rutland-VT
West-Ossipee-NH 4 --> 1w-3-2 1e-3-2 --> 3 Rutland-VT
West-Ossipee-NH 4 <-- 1w-3-2 1e-3-2 <-- 3 Rutland-VT
West-Ossipee-NH 4 --> 1w-3-3 1e-3-3 --> 3 Rutland-VT
West-Ossipee-NH 4 <-- 1w-3-3 1e-3-3 <-- 3 Rutland-VT
Boscawen-NH* ? --> 1w-4-1 1e-4-1 --> 5 Keene-NH
Boscawen-NH* ? <-- 1w-4-1 1e-4-1 <-- 5 Keene-NH
- --> 1w-4-2 1e-4-2 --> 7 Suncook-NH
- <-- 1w-4-2 1e-4-2 <-- 7 Suncook-NH
- <--- 1w-4-3 1e-4-3 --> -
- --> 1w-4-3 1e-4-3 <-- -
- 1w-5 1e-5 -
.. .
.. .
.. .
- 1w-16 1e-16 -
*/
;
