Platform Descriptions
3-62 Issue 8.0 July 2002
Condensed High-Speed Shelf Interfaces 3
Front access cabling (for ordering and power) is provided through the
Interconnection and Filter Panel (Figure 3-33).
Figure 3-33. Interconnection and Filter Panel (Condensed
High-Speed Shelf)
A
B
C
D
E
Line 1W
J256A
Line 1E
J276A
Line 1W
J252A
Line 1E
J272A
Line 1W
J254A
Line 1E
J274A
Line 1W
J251A
Line 1E
J271A
Intraoffice
LAN
J277A
F
J10A
adr05005.00eJF0081896r7.1
