Craft Interface Terminal Usage
11-76 Issue 8.0 July 2002
Example 21 - FAULT-Retrieve-Network Alarms 11
Releases 3 and Later (Release 2 shown in separate example.)
The above report shows the alarm and status conditions that are currently being
reported in the maintenance subnetworks. If no alarms exist, one of the following
reports will be generated: There are no active system alarms or There
are no active alarms in the alarm group. If a warning statement is
displayed, the information is incomplete due to one or more of the following
conditions:
â– The OC-48 DCC has been declared failed in both an East and West
direction.
â– The OC-3 DCC has been declared failed in the local network element.
â– The SECURITY-Set-FECOM command has been disabled. The status is
shown in the "Remote Activity Reporting" column of the "Far End
Communication Configuration Report."
â– If one or more nodes are "unreachable" because of a double ring failure.
The warning statement ("information incomplete" message) is appended to the
report header and appears as follows for Releases 4.1 and 5.0. The warning
statement for Release 3 and 4.0 does not include Retrieve-Map-Ring and is not
shown.
Warning! The information displayed may be incomplete. Check
Retrieve-Map-Network, Retrieve-Far End
Communications Retrieve-Alarm for further details.
Delta-1 93-01-19 23:15:15 EST
M Retrieve-Network Alarms: COMPLD
/* Network Alarms Report
==========================================================================
System Date Time TID Product Local
Alarm Type Ring
==========================================================================
MN 01-19 21:18:47 Delta-2 FT-2000 Yes
MN 01-19 21:18:27 Delta-3 FT-2000 Yes
MN 01-19 21:20:57 Echo-1 DDM-2000 no
*/
Information below is for Releases 3, 4.0, 4.1 and 5
==========================================================================
System Date Time TID
Alarm
==========================================================================
