Craft Interface Terminal Usage
Issue 8.0 July 2002
11-63
Example 13 - CONFIGURATION-Retrieve-EC1 11
Releases 4.1 and Later (Use the CONFIGURATION category.)
The fields of the report are described below:
Port
Address
- Shows a specific slot and low-speed port (1, 2, or 3) of an
STS1E circuit pack (and line only for 1x1 end terminal).
Alarm
Level
- Shows the highest severity user panel LED that is lit which is
the alarm that is assigned to the incoming EC1signal failure. If
no LEDs are lit, then status is shown as NA (not alarmed) or
NR (not reported) if provisioned as such.
Signal
Degrade
Threshold
- Shows the provisioned signal degrade threshold, either −3or
−6.The example shows a −6, meaning the error rate 10
-6
.
Port State - Shows the memory administrative state of the port from the
STS1X or from the OC-48 line; such as, is for in service, auto
for automatic, and nmon for not monitored.
Delta-1 94-02-15 09:15:15 EST
M Retrieve-EC1:All: COMPLD
/* EC1 Port Provisioning Report
=====================================================================
Alarm Signal --Port State--
Port Level Degrade from from
Address NE FE Threshold STSX1 OC48
=====================================================================
ls-1a-1 MJ MN -6 is is
ls-1a-2 MJ MN -6 auto auto
ls-1a-3 CR MN -6 is is
.
.
.
ls-8b-3 MN MN -3 is is
;
