Lucent Technologies FT-2000 OC-48 User Manual

Craft Interface Terminal Usage
11-54 Issue 8.0 July 2002
Example 10 - CONFIGURATION-Retrieve-Crossconnection-STS3 11
Releases 5 and 6
The above report shows an STS-3 cross-connection map from an FT-2000 OC-48
Add/Drop-Rings Terminal. The West (left of center) and East (right of center)
tributaries are displayed concurrently down the page in ascending order.
Additional information on cross-connections is in Volume I, Section 8,
"Cross-Connections."
Lucent Technologies-FT-2000 96-07-19 23:15:15 EST
M Retrieve-Crossconnection-STS3: COMPLD
/* STS-3 Cross-Connection Map Report (State: ... = standby --- = active)
==============================================================================
Destination/Source Cross-Connection Source/Destination
==============================================================================
NOTICE! Please use the Retrieve-Squelch Map-STS1 command to
check for possible additional information.
Worcester-MA 1w-1 ---> 8a 1b ---> 1e-1 *Chicopee-MA
1w-1 1b ...> 1e-1
1w-1 1a <--- 1e-1
1w-1 1b <--- 1e-1 Springfield-MA
-1w-2 1e-2-
West-Ossipee-NH 1w-3 ----------------> 1e-3 Rutland-VT
1w-3 ---> 2a 1e-3
1w-3 ---> 2b 1e-3
1w-3 <... 2a 1e-3
1w-3 <--- 2b 1e-3
West-Ossipee-NH 1w-3 <................ 1e-3 Rutland-VT
Boscawen-NH 1w-4 ----------------> 1e-4 Keene-NH
1w-4 3a ...> 1e-4
1w-4 3a <--- 1e-4
Boscawen-NH 1w-4 <---------------- 1e-4 Keene-NH
Jamaica-VT 1w-5 <---------------->1e-5 Suncook-NH
Jamaica-VT 1w-5 --> 4a 4b <--- 1e-5 Suncook-NH
Quabbin-MA 1w-6 ------------------> 1e-6 *?
Quabbin-MA 1w-6<------------------ 1e-6 Pittsfield-MA
Goffstown-NH* 1w-7 ---> 5b 6a <--> 1e-7 Alfred-ME
Goffstown-NH* 1w-7<---> 8b 7a <--- 1e-7
1w-7 7b <--- 1e-7 Alfred-ME
-1w-8 1e-8 -
::
- 1w-16 1e-16 -
*/
;
