Platform Descriptions
3-56 Issue 8.0 July 2002
The Low-Speed Shelf - System Controller has two front covers (Figure 3-31).
One covers the interconnection panel and the other covers the circuit packs.
Openings are provided in the top cover that allow the user panel to show through
and provide access to the CIT port. The covers are hinged and can be easily
removed for maintenance access.
Figure 3-31. Low-Speed Shelf - System Controller (with Covers)
Low Speed Shelf - System Controller
