Platform Descriptions
3-38 Issue 8.0 July 2002
Table 3-5 also provides circuit pack slot/circuit pack code/software compatibility
information.
Note
: Release 2.0.1-RPTR has been discontinued.
* The 39B1 and 39C1 OC48 REGENR circuit packs were discontinued in December 1995.
†The LAA23 SYSCTL circuit pack has been discontinued and replaced with the LAA23B
SYSCTL circuit pack.
Circuit pack keying prevents circuit packs from being accidentally inserted in incorrect slots.
For detailed circuit pack descriptions and software compatibility information, refer to
Volume I, Section 7, "Circuit Pack Descriptions."
Repeater Shelf — System Controller Interfaces 3
Front access cabling is provided through the interconnection panel (Figure 3-21).
Table 3-5. Repeater Shelf — System Controller Circuit Pack
Slot/Circuit Pack Code/Software Compatibility
Supported Circuit Compatible Software (Note)
Circuit Pack Slot Pack Codes R2.1.0-RPTR R4.0.0-RPTR R6.0.0-RPTR
REGENR 1EW and
1WE
39B1 OC48 REGENR* XXX
39B2 OC48 REGENR X X X
39C1 OC48 REGENR* XXX
39C2 OC48 REGENR X X X
39J2 OC48 REGENR X X
39R2 OC48 REGENR X
39S2 OC48 REGENR X
ROHCTL 1 and P LAA14 OW X X X
SYSCTL LAA23 SYSCTL†X X X
LAA23B SYSCTL X X X
SYSMEM LAA25 SYSMEM X X X
