Technical Specifications
Issue 8.0 July 2002
10-15
FT-2000 OC-48 Lightwave System and the
FT-Lightwave Booster Amplifier 10
Table 10-11 shows the transmission distances of the FT-2000 OC-48 Lightwave System with
the FT-Lightwave Booster Amplifier.
Notes
:
1. This dispersion limit applies only to 1.5 µm STD and LBA performance transmitters used with standard fiber.
2. Standard fiber assumes a dispersion limit of 18 psec/nm per km. It also assumes a fiber lo
(including splice loss) of 0.25 dBm/km at 1.5 µm.
3. Dispersion-shifted fiber assumes a 0.25 dB/km loss at 1.5 µm. On dispersion-shifted fiber, both versions
of the 1.5 µm transmitters support the same distance.
4. The 1.5 µm LBA transmitter is screened for dispersion.
Table 10-11. Transmission Distances with the FT-Lightwave Booster Amplifier
Maximum Distance
Dispersion Limit (Note 1)
Standard Fiber (SF)
(Note 2)
Dispersion-Shifted
Fiber(DSF)(Note3)
FT-LBA
Loss Budget
OC48 TRMTR
(A/D 1.5 STD)
OC48 TRMTR A/D
(1.5 LBA)
(1.5 LBA, W1)
(1.5 LBA, W2)
(STS1 1.5 LBA, W1)
(STS1 1.5 LBA, W2)
(Note 4)
OC48 TRMTR
(A/D 1.5 STD)
OC48 TRMTR A/D
(1.5 LBA)
(1.5 LBA, W1)
(1.5 LBA, W2)
(STS1 1.5 LBA, W1)
(STS1 1.5 LBA, W2)
(Note 4)
OC48 TRMTR A/D
(1.5 STD)
(1.5 LBA)
(1.5 LBA, W1)
(1.5 LBA, W2)
(STS1 1.5 LBA, W1)
(STS1 1.5 LBA, W2)
9 dBm 32 dB (SF) 1800 psec/nm 2160 psec/nm 100 km 120 km 132 km
33 dB (DSF) 100 km 120 km 62 miles 75 miles 82 miles
12 dBm 35 dB (SF) 1800 psec/nm 2510 psec/nm 100 km 140 km 144 km
36 dB (DSF) 100 km 140 km 62 miles 87 miles 89 miles
16 dBm 39 dB (SF) 1800 psec/nm 2520 psec/nm 100 km 140 km 160 km
40 dB (DSF) 100 km 140 km 62 miles 87 miles 99 miles
