Craft Interface Terminal Usage
Issue 8.0 July 2002
11-107
Example 33 - PERFORMANCE-Retrieve-PM-T3 11
Releases 4 and Later
The above report, which can be a multiple page report, shows the current
performance-monitoring data (day and quarter-hour) for a T3 (DS3 line and DS3
path). Data is collected from the signal coming from the cross-connections (DS3
line) and from the OC-48 line (DS3 path). When a greater than sign (>) is
displayed, it means the violations are greater than the maximum value for the
parameter. When a question mark ("?") is displayed, it means corrupted data or
an incomplete time cycle for that parameter. When a hyphen ("-") is displayed, it
means the data is unavailable, such as any port in the NMON or AUTO state. An
asterisk (*) is displayed whenever the threshold-crossing alert (TCA) is reached.
This report is not available at the repeater site.
Delta-1 91-07-15 23:15:15 EST
M Retrieve-Performance Monitoring-T3:1-1A-All: COMPLD
/* DS-3 Performance Monitoring Status Report
Bin Start Time: quarter hour registers at yy-mm-dd hh:mm:ss
day registers at yy-mm-dd hh:mm:ss
==========================================================================
Start -DS3 Line- ------------- DS3 Path --------------
Address Time ES-L CV-P ES-P SES-P SAS-P UAS-P
==========================================================================
ls-1a-1 Today 1* 11 0 5 4 3
(F&M-bit) -------------------------------------------------------------
09:00 0 0 3 3 3 19
==========================================================================
ls-1a-2 Today 25 2 0 45 3 19
(F&M-bit) -------------------------------------------------------------
09:00 0 00000
==========================================================================
ls-1a-3 Today 0 0 0 0 0 0
(P-bit) -------------------------------------------------------------
09:00 0 00000
==========================================================================
ls-1b-1 Today 111* 10 0 5 4 3
(P-bit) -------------------------------------------------------------
09:00 0 80 3 3 3 19
==========================================================================
ls-1b-2 Today 25 2 0 5 3 19
(F&M-bit) -------------------------------------------------------------
09:00 0 00000
==========================================================================
ls-1b-3 Today 1 0 0 0 0 0
(F&M-bit) -------------------------------------------------------------
09:00 0 00000
*/
;
Information below is for Release 4.0 and Release 4.1
/* DS-3 Performance Monitoring Status Report
Last initialized: quarter hour registers at yy-mm-dd hh:mm:ss
day registers at yy-mm-dd hh:mm:ss
==========================================================================
Start -DS3 Line- ------------ DS3 Path -------------
Address Time ES CV ES SES SAS UAS
==========================================================================
