Craft Interface Terminal Usage
11-72 Issue 8.0 July 2002
Example 19 - CONFIGURATION-Retrieve-Map-Network 11
Releases 6 and Later
This report lists all network elements (NEs) in the maintenance subnetwork (limit
of 64 network elements). The NEs above the dashed line are in the local ring
arranged in a West-to-East sequence. And below the dashed line, all other NEs
are accessible via DCC channels (both OC-48 and OC3) and/or intra-office LANs
(IAO-LANs). The report shows that the local ring network is complete (DCC
continuity is good). An incomplete/open ring network is indicated by FAIL in the
DCC Status column. The fields of the report are described below:
TID - Shows the target identifier assigned to the node (up to 20
characters).
DCC Status - Shows either good or FAIL for the data communications channel
(DCC) between the local network element and the remote network
element.
Product Type - Shows the listed network element as FT-2000, DDM-OC3
(DDM-2000 OC-3), DDM-OC12 (DDM-2000 OC-12), DACS IV
(DACS IV-2000), SLC
â
-2000, FbrRch (FiberReach), and ?
(unknown, foreign, and all others).
DSNE - Shows if this network element is serving as the directory service
network element (DSNE) in the subnetwork.
ASNE - Shows if this network element is serving as an alarm server network
element (ASNE) in the subnetwork.
Alarm Group - Shows a value from zero to 255 where the value represents a
SONET maintenance sub-branch (SMSB) alarm group of network
elements that exchange alarm information. A zero (0) means no
remote alarm information is exchanged.
/* Network Map Report
===========================================================================
DCC Product Alarm
TID Status Type DSNE AGNE Group
===========================================================================
LOCAL-TID-GOES-HERE good FT-2000 yes 251
ANOTHER-TID-HERE-0 good FT-2000 251
TID-3-GOES-HERE good FT-2000 251
LAST-TID-LISTED good FT-2000 251
---------------------------------------------------------
ANOTHER-TID-HERE-1 good FT-2000 251
ANOTHER-TID-HERE-2 good FT-2000 251
ANOTHER-TID-HERE-3 good FT-2000 251
ANOTHER-TID-HERE-4 good DDM-OC3 yes 253
ANOTHER-TID-HERE-5 good DDM-OC3 253
ANOTHER-TID-HERE-6 good DDM-OC12 yes 253
ANOTHER-TID-HERE-7 good DACS IV yes 253
ANOTHER-TID-HERE-8 good FbrRch 253
ANOTHER-TID-HERE-9 good ? ?
*/
