NTP-006: Acceptance 365-575-102
Page2of6 Issue8.0,July2002
NOTE:
It is assumed that installation of the FT-2000 add/drop-rings terminal has
been completed (including circuit pack installation) for the engineered
configuration. It is further assumed that the add/drop-rings terminal is
powered and running. If at any point in this procedure the FT-2000
add/drop-rings terminal fails to respond in the indicated way, refer the
trouble to installation personnel.
NOTE:
Ignore the LEDs at the user panel during this test.
Inspect the FT-2000 add/drop-rings terminal for
obvious damage
—
2.
NOTE:
All connections to other equipment must be removed.
At the DSX-3, STSX-1, and/or
LGX
â
cross-connect panel or equivalent, remove all
DS3, EC1, OC3, IS3 and/or OC12 connections
to the FT-2000 terminal. All electrical output
ports associated with slots equipped with
DS3/EC1 packs must be terminated with
75-ohms. Make a record of these
disconnections so they can be replaced after
the test.
—
3. Loop back all high-speed OC-48 lines (so that the
OUT jack of TRMTR 1E is connected to the IN jack of
RCVR 1E and the OUT jack of TRMTR 1W is
connected to the IN jack of RCVR 1W).
DLP-500
4. If required, connect the craft interface terminal (CIT)
to the local FT-2000 network element and condition
it.
DLP-501
5. Log in to the CIT by entering "cit expert". This is
required when using the
CONFIGURATION-Set-Synchronization
command in Steps 7 and 15.
—
DO ITEMS BELOW IN ORDER LISTED . . . . . . . FOR DETAILS, GO TO
