Lucent Technologies FT-2000 OC-48 User Manual

Platform Descriptions
Issue 8.0 July 2002
3-57
Condensed High-Speed Shelf 3
Purpose of Condensed High-Speed Shelf 3
Each Condensed High-Speed Shelf
*
serves as an interface for OC-48 high-speed
lines 1W and 1E. The Condensed High-Speed Shelf (Figure 3-32) consists of the
fully connectorized interconnection panel, a filter panel, and 12 circuit pack slots.
It measures 14.25 inches high by 21.5 inches wide by 12 inches deep and fits into
a standard 23-inch wide network bay framework.
Condensed High-Speed Shelf Circuit Packs 3
The Condensed High-Speed Shelf (Figure 3-32) provides the following circuit
pack slots:
■ TRMTR 1W: One slot is provided for the 739B2
†
, 739C2
†
, 739E[1-16],
739H[1-16], 739J2
†
,739J3
†
, 739R2
†
, 739S2
†
, 739B4, 739J4, 739B5,
739C5, 739J5, 739P5, 739R5, or 739S5 OC48 Transmitter, Add/Drop
(OC48 TRMTR [A/D]) circuit pack for OC-48 high-speed line 1W. The
739J3 OC48 TRMTR (A/D) circuit pack is compatible with Release
5.0.1-ADR or later software. The 739R2 and 739S2 OC48 TRMTR (A/D)
circuit packs are compatible with Release 6.0.0-ADR or later software. The
739B4, 739J4, 739B5, 739C5, 739J5, 739P5, 739R5, and 739S5 OC48
TRMTR (A/D) circuit packs are compatible with Release 7.0.0-ADR or later
software. The 739E[1-16] circuit packs are compatible with Release
7.2.0-ADR and later software.
■ RCVR 1W: One slot is provided for the 839B2
†
, 839B4B, or 839B5 OC48
Receiver, Add/Drop (OC48 RCVR [A/D]) circuit packs for OC-48 high-
speed line 1W. The 839B4B and 839B5 OC48 RCVR (A/D) circuit packs
are compatible with Release 7.0.0-ADR or later software. The 839E5 circuit
pack is compatible with Release 7.2.0 and later software.
■ TRMTR 1E: One slot is provided for the 739B2
†
,739C2
†
, 739E[1-16],
739H[1-16], 739J2
†
,739J3
†
, 739R2
†
, 739S2
†
, 739B4, 739J4, 739B5,
739C5, 739J5, 739P5, 739R5, or 739S5 OC48 Transmitter, Add/Drop
(OC48 TRMTR [A/D]) circuit pack for OC-48 high-speed line 1E. The
739B4, 739J4, 739B5, 739C5, 739J5, 739P5, 739R5, and 739S5 OC48
TRMTR (A/D) circuit packs are compatible with Release 7.0.0-ADR or later
software. The 739E[1-16] circuit packs are compatible with Release 7.2.0
and later software.
* The Condensed High-Speed Shelf is used only on FT-2000 OC-48 Add/Drop-Rings
Terminal for two-Fiber Rings equipped with the J68974D FT-2000 OC-48 Enhanced
Lightwave Terminating Bay.
† These transmitters and receivers are rated discontinued availability (DA) as of 06/97.
