Lucent Technologies FT-2000 OC-48 User Manual

Technical Specifications
10-32 Issue 8.0 July 2002
Power Specifications 10
NOTE:
Consult FPD 804-911-168 for complete engineering of battery plant and
feeders.
Voltage Range, all components ................................... −42.75 to −60 V DC
Power Feeders ............................................................. Two −48 V power feeders ("A"
and "B")
Fuse Size (per shelf) ................................................... 10 amps
Maximum Power Dissipation:
— FT-2000 OC-48 Add/Drop-Rings Terminal ................
for 2–Fiber Rings
507 watts (72 wtts/ft
2
)
— FT-2000 OC-48 Dual Lightwave ............................
Terminating Bay
1142 watts (162 watts/ft
2
)
— FT-2000 OC-48 Repeater Shelf 175 watts (25 watts/ft
2
)
— FT-2000 OC-48 Repeater Shelf
(One Repeater Shelf - System Controller)
175 watts (25 watts/ft
2
)
— FT-2000 OC-48 Repeater Shelf
(Two Repeater Shelf - System Controllers)
350 watts (50 watts/ft
2
)
— FT-2000 OC-48 Repeater Shelf
(Three Repeater Shelf - System Controllers)
525 watts (75 watts/ft
2
)
Current Drains per Feeder Cable:
Nominal (List 1
*
)(@–48 V DC)
—FT-2000 OC-48 Add/Drop-Rings ............................
Terminal for 2-Fiber Ring 5.3 amps
—FT-2000 OC-48 Dual Lightwave Terminating Bay.. 11.9 amps
— FT-2000 OC-48 Repeater Shelf 1.8 amps
— FT-2000 OC-48 Repeater Shelf
(One Repeater Shelf - System Controller)
1.8 amps
— FT-2000 OC-48 Repeater Shelf
(Two Repeater Shelf - System Controllers)
3.6 amps
— FT-2000 OC-48 Repeater Shelf
(Three Repeater Shelf - System Controllers)
5.5 amps
Maximum (List 2
†
)(@–42.75 V DC)
—FT-2000 OC-48 Add/Drop-Rings ............................
Terminal for 2-Fiber Ring 11.9 amps
—FT-2000 OC-48 Dual Lightwave Terminating Bay.. 26.7 amps
— FT-2000 OC-48 Repeater Shelf 4.1 amps
