Craft Interface Terminal Usage
Issue 8.0 July 2002
11-75
Releases 3 and 4.0
The above reports show the current values of the parameters used in addressing
the ring nodes. The first report shows a complete/close ring and the second
report shows an incomplete/open ring. The topmost entry is the node where the
report is requested followed by all remaining nodes in a west-to-east direction.
When data is unavailable, a "?" appears in the appropriate column of the report.
The fields of the report are described below:
NID - Shows the node identifier, 0 through 15.
TID - Shows the target identifier assigned to a node.
NSAP - Shows the factory-provisioned character string of the network services
access point. The NSAP resides in the SYSCTL circuit pack.
Comm
Stat
- Shows either good or FAIL for the data communications channel (DCC)
between the local network element and a remote network element.
Delta-1 93-01-07 08:30:45
M Retrieve-Map-Ring: COMPLD
/* Ring Map Report
===============================================================================
Comm
NID TID NSAP Stat
===============================================================================
0 Delta-1 39.1a3b.00.911ff4.1020.2112.3456.2181954aa677.ff good
1 Delta-2 39.1a3b.00.911ff4.1020.2112.3456.2181954aa678.ff good
2 Delta-3 39.1a3b.00.911ff4.1020.2112.3456.2181954aa679.ff good
*/
;
Delta-1 93-01-07 08:30:45
M Retrieve-Map-Ring: COMPLD
/* Ring Map Report
===============================================================================
Comm
NID TID NSAP Stat
===============================================================================
Notice: Ring Incomplete/Open
0 Delta-1 39.1a3b.00.911ff4.1020.2112.3456.2181954aa677.ff good
1 Delta-2 39.1a3b.00.911ff4.1020.2112.3456.2181954aa678.ff good
2 Delta-3 39.1a3b.00.911ff4.1020.2112.3456.2181954aa679.ff FAIL
*/
;
