Lucent Technologies FT-2000 OC-48 User Manual

365-575-102 Detailed Level Procedure: DLP-502
Issue 8.0, July 2002 Page 3 of 4
Figure 1 – FT-2000 End Terminal Example (Service Line Only)
Figure 2 – FT-2000 End Terminal Example (Service Line and Protection Line)
Lucent Technologoes FT-2000 96-11-07 08:30:45 EST
M Test-Auto:All: COMPLD
/* Test Auto Turnup Report - Local Test
=============================================================
Line 1: --TG-- --LSSW--
TRMTR RCVR 1 2 IN OUT OHCTL LNCTL
gggg gggg
*/
;
-------------- LS INTFC--------------
1122334455667788PP
ABABABABABABABAB12
ggggggggggggggggg-
Lucent Technologies FT-2000 96-11-07 08:30:45 EST
M Test-Auto:All: COMPLD
/* Test Auto Turnup Report - Local Test
=====================================================================
Line 1: --TG-- --LSSW--
-------------------------------------------------------------------------
Line P: --TG-- --LSSW--
TRMTR RCVR 1 2 IN OUT OHCTL LNCTL
gggg g g - g
*/
;
-------------- LS INTFC--------------
1122334455667788PP
ABABABABABABABAB12
ggggggggggggggggg-
-------------- LS INTFC--------------
1122334455667788PP
ABABABABABABABAB12
ggggggggggggggggg-
TRMTR RCVR 1 2 IN OUT OHCTL LNCTL
gggg g g - g
