Craft Interface Terminal Usage
Issue 8.0 July 2002
11-121
Releases 4, 5, and 6 (Use the PERFORMANCE category.)
The report shows the current performance-monitoring threshold crossing alert
(TCA) values for the STS-48 section. This report is not available at the repeater
site.
Address - Shows the specific OC-48 line.
Bin - Shows the quarter-hour (QH) and the day bins.
TCA Report - Shows if the automatic reporting of TCAs is enabled or
disabled.
BER - Shows the provisioned bit error rate for the QH and day bins
that will cause a TCA.
CV-S - Shows the provisioned number of code violations for the QH
and day bins that will cause a TCA.
ES-S - Shows the provisioned number of errored seconds for the
QH and day bins that will cause a TCA.
SES-S - Shows the provisioned number of severely errored seconds
for the QH and day bins that will cause a TCA.
SEFS-S - Shows the provisioned number of section errored frame
seconds for the QH and day bins that will cause a TCA.
Delta-1 93-01-15 13:15:15 EST
M Retrieve-PM Threshold-Section:All: COMPLD
/* STS-48 Section Performance Monitoring Threshold Value Report
==========================================================================
TCA --------- STS-48 Section (B1) --------
Address Bin Report BER CV-S ES-S SES-S SEFS-S
==========================================================================
line-1e QH Enable -9 1000 25 10 5
Day Enable -9 1000 3 250 50
line-1w QH Disable -9 1000 25 10 5
Day Disable -9 1000 3 250 50
*/
;
Information below is for Release 4.0 and Release 4.1
/* STS-48 Section Performance Monitoring Threshold Value Report
==========================================================================
TCA --------- STS-48 Section (B1) --------
Address Bin Report BER CV ES SES SEFS
==========================================================================
