DLP-512: Detailed Level Procedure 365-575-102
Page 10 of 14 Issue 8.0, July 2002
Figure 2 – FT-2000 OC-48 ADR High-Speed Fiber Routing
Line 1W
TRMTR RCVR
Line 1E
TRMTR RCVR
Enhanced High Speed Shelf
Interconnection Panel
Fiber
Protection
Tubing or
Panduit
TopofFT-2000BayFrame
Fiber Protection Trough
To
Lightguide
Cross
Connect
