DLP-535: Detailed Level Procedure 365-575-102

Page2of6 Issue8.0,July2002

2. From office records, determine the location of the next ring node and send a

Trouble Report to the personnel responsible for maintaining that site.

NOTE:

The source of the incoming signal condition is the next ring node in the

direction of the incoming signal (or the other end terminal if this is a

point-to-point network).

incoming OC48 B1 parity error Step 6

incoming OC-48 invalid F byte Step 8

incoming OC-3 line RFI/yellow Step 6

incoming OC-12 line RFI/yellow Step 6

incoming OC-48 line RFI/yellow Step 6

incoming OC-3 LOF Step 6

incoming OC-12 LOF Step 6

incoming OC-48 LOF Step 6

incoming OC-3 LOS Step 6

incoming OC-12 LOS Step 6

incoming OC-48 LOS Step 6

incoming OC-48 LOS/LOF Step 6

incoming OC-3 SD Step 6

incoming OC-12 SD Step 6

incoming OC-48 SD Step 6

incoming OC-3 SF Step 6

incoming OC-12 SF Step 6

incoming OC-48 SF Step 6

incoming sync ref failure Step 4
