Administration and Provisioning
8-62 Issue 8.0 July 2002
At node 2 (primary node), a 1-way-DRI cross-connection is entered by
specifying:
Source low-speed interface slot
*
(slot 5A)
Source low-speed port (1)
Destination line (line 1W)
Destination STS-3 tributary (tributary 6)
Destination STS-1 tributary (tributary 1)
Destination node TID (node 0 TID)
Secondary node TID (node 3 TID).
At node 3 (secondary node), a 1-way add cross-connection is entered by
specifying:
Source (STS-1 port)
Source low-speed interface slot* (slot 4B)
Source low-speed port (1)
Destination line (line 1W)
Destination STS-3 tributary (tributary 6)
Destination STS-1 tributary (tributary 1)
Destination node TID
†‡
(node 0 TID).
At node 1, a 1-way through cross-connection is entered by specifying:
Source (tributary)
Source line (line 1E)
Source STS-3 tributary (tributary 6)
Source STS-1 tributary (tributary 1)
Source node TID (node 3 TID)
Destination (tributary)
Destination node TID†‡ (node 0 TID).
* If the specified slot is part of a slot pair (for example, slot 1A and 1B) that has been
provisioned for the OC-3 1+1 protected mode, specifying one slot also includes the
companion slot. The same type of logic applies to OC-12 1+1 (Release 7.1 and later
releases) protected mode.
Entering a question mark (?) in response to the TID prompt will display a point-and-shoot
list of available addresses in the OC-48 ring. Enter the Retrieve-Map-Ring command to
update the point-and-shoot list.
If an STS-1 tributary is bridged at one or more nodes in a ring, the last node where the
low-speed signals are terminated must be specified as the destination node.
