Administration and Provisioning
Issue 8.0 July 2002
8-73
â– At node 0, traffic is rolled from low-speed interface slot 2B, port 2, to
low-speed interface slot 4A, port 1, by specifying:
— Source (STS-1 port)
— Source low-speed interface slot
*
(slot 2B)
— Source low-speed port (2)
— Destination line (line 1E)
— Destination STS-3 tributary (tributary 6)
— Destination STS-1 tributary (tributary 3)
— New cross-connection type (1-way)
— New source (STS-1 port)
— New source low-speed interface slot* (slot 4A)
— New source low-speed port (1).
* If the specified slot is part of a slot pair (for example, slot 1A and 1B) that has been
provisioned for the OC-3 1+1 (Release 5 or later releases) protection mode, specifying one
slot also includes the companion slot. The same type of logic applies to OC-12 1+1
(Release 7.1 or later releases) protected mode.
