Craft Interface Terminal Usage
11-84 Issue 8.0 July 2002
Releases 5 and 6
The above report shows the provisioning information and attributes of an OC3
slot. It provides information on the severity of the alarm implied by the failure of
the OC3 slot, the signal degrade threshold, and the memory administrative state.
Port Addr - Shows a specific low speed interface slot (physical) address.
Alrm Lvl - Shows the provisioned service affecting (SA) alarm level for the
slot (CR, MJ, MN, NA, or NR).
SD Thrsh - Shows the provisioned signal degrade threshold value (-5, -6, -7,
-8, -9) to base 10 of the bit error rate.
Output AU4
Map
- Shows the provisioned AU4 mapping of either SONET or
synchronous digital hierarchical (SDH).
Line Code - Shows the optical line code of "nrz".
Wave- Lngth - Shows the optical wavelength of "1310".
Provisioned-
Mode
- Shows the provisioned protection switching mode (1+1 or 0x1) in
the "from OC48" direction and the "from OC3" direction.
Operating-Mode - Shows the actual operating protection switching mode (1+1 or
0x1) in the "from OC48" direction and the "from OC3" direction.
Payload - Shows the signal type (-3 or -3C) being forwarded through the
OC3 circuit pack in the "from OC48" direction and the "from OC3"
direction.
Delta-1 94-06-15 23:15:15 EST
M Retrieve-OC3:All: COMPLD
/* OC3 Provisioning Report
==============================================================================
Output Provisioned Operating
Port Alrm SD AU4 Line Wave- Mode Mode Mode Mode Payload
Addr Lvl Thrsh Map Code Lngth (from (from (from (from (from (from
OC48) OC3) OC48) OC3) OC48) OC3)
==============================================================================
ls-1a CR -6 SONET nrz 1310 1+1 1+1 1+1 1+1 -3 -3C
ls-1b CR -6 SONET nrz 1310 1+1 1+1 1+1 1+1 -3C -3C
ls-2a MJ -8 SONET nrz 1310 0x1 0x1 0x1 0x1 -3 -3
ls-2b MJ -8 SONET nrz 1310 0x1 0x1 0x1 0x1 -3 -3
ls-3a MN -6 SDH nrz 1310 1+1 1+1 0x1 1+1 -3 -3
ls-3b NA -6 SDH nrz 1310 1+1 1+1 1+1 1+1 -3C -3C
...
...
ls-8b NA -8 SDH nrz 1310 0x1 0x1 0x1 0x1 -3C -3C
*/
;
