Craft Interface Terminal Usage
11-86 Issue 8.0 July 2002
Release 3 and Later
The above report shows provisioned information for each addressed high-speed
line at an FT-2000 add/drop-rings terminal, whereas the report on the next page
shows the information for an FT-2000 repeater bay/shelf.
Line
Address
- Shows the OC-48 line(s) selected for the report.
Line Code - Shows the non-return-to-zero (nrz) line code.
Signal
Degrade
Threshold
- Shows the provisioned threshold value. This value
determines when a signal degrade condition will be
declared. The value is the line parity error rate for the
specified line(s); for example, -5 is error rate 10
-5
.
Wave-Length - Shows the provisioned optical line wavelength, either
1310 or 1550 nanometers. If a hyphen ("-") appears, it
means the line is unequipped; for example, no TRMTR
circuit pack inserted.
PS*
Priority
- Only for Release 1.1.1 and Release 2.1.0. Shows the
provisioned protection switch priority of the line, either
"HIGH" or "LOW."
__________
* This column only appears in an FT-2000 end terminal report.
Delta-1 94-06-15 23:15:15 EST
M Retrieve-OC48:All: COMPLD
/* OC-48 Line Provisioning Report
=============================================================
Line Line Signal Degrade Wave-
Address Code Threshold Length
=============================================================
line-1e nrz -5 1310
line-1w nrz -5 1310
*/
;
To Next Page
