365-575-102 Acceptance: NTP-009
Issue 8.0, July 2002 Page 11 of 12
Figure 5 – Testing Local FT-2000 Ring (Four Nodes) and Two External Network
Figure 6 – End-to-End Test Arrangement (for Slot 5B)
Note: Two DRI cross-connections to the outside. One DRI cross-connection terminates
in an external network and the other DRI cross-connection terminates directly to test sets.
Local
FT-2000
Ring
Test Set
S
P
External
Network
P’
S’
Test Set
TR
In Out
5B-1
FT-2000
In Out
5B-1
FT-2000
Test set
STS-1
TR
Test set
STS-1
