Configuration Path
[IPSec]-[Authentication]
Key Management
IKE+X.509 Local Certificate: HQCRT Remote Certificate: BranchCRT
Local ID
User Name Network-A
Remote ID
User Name Network-B
Configuration Path
[IPSec]-[IKE Phase]
Negotiation Mode
Main Mode
X-Auth
None
For Network-B at Branch Office
Following tables list the parameter configuration as an example for the "My Certificate" function used in the user
authentication of IPSec VPN tunnel establishing, as shown in above diagram. The configuration example must be combined
with the ones in following two sections to complete the whole user scenario.
Use default value for those parameters that are not mentioned in the tables.
Configuration Path
[My Certificate]-[Local Certificate Configuration]
Name
BranchCRT Self-signed: □
Key
Key Type: RSA Key Length: 1024-bits
Subject Name
Country(C): AU State(ST): NSW Location(L): Sydney
Organization(O): NetCommWireless Organization Unit(OU): NTC
Common Name(CN): NTCCRT E-mail: ntccrt@netcommwireless.com
Configuration Path
[IPSec]-[Configuration]
IPSec
■ Enable
Configuration Path
[IPSec]-[Tunnel Configuration]
Tunnel
■ Enable
Tunnel Name
s2s-102
Interface
WAN 1
Tunnel Scenario
Site to Site
Operation Mode
Always on
