Item Notes Description
OpenVPN
Server
Disabled by default.
Click

Enable
to activate OpenVPN Server functions.
Protocol
Mandatory field.
Default setting:
TCP
Select the Protocol for connecting to the OpenVPN Server:
TCP
or
UDP
TCP
– The TCP protocol will be used to access the OpenVPN Server, and
Port will be automatically set at 4430.
UDP
– The UDP protocol will be used to access the OpenVPN Server, and
Port will be automatically set at 1194.
Port
Mandatory field.
Default setting:
4430
Specify the Port for connecting to the OpenVPN Server.
Value Range: 1 - 65535.
Tunnel Scenario Mandatory field.
Default setting:
TUN
Specify the type of Tunnel Scenario for connecting to the OpenVPN
Server. It can be TUN for TUN tunnel scenario, or TAP for TAP tunnel
scenario.
Authorization
Mode
Mandatory field.
Default setting:
Static
Key
Select the authorization mode for the OpenVPN Server:
TLS
or
Static
Key
TLS –
OpenVPN will use TLS authorization mode, and the following items
CA Cert.
,
Server Cert.
and
DH PEM
will be displayed.
The
CA Cert
. can be generated in
Object Definition > Certificate >
Trusted Certificate
.
The
Server Cert.
can be generated in
Object Definition >
Certificate > My Certificate
.
Static Key
– The OpenVPN will use static key (pre-shared) authorization
mode, and the following parameters are displayed:
Local Endpoint
IP Address
,
Remote Endpoint IP Address
and
Static Key
Note
–
Static Key
will be available only when
TUN
is chosen in
Tunnel Scenario.
Local Endpoint
IP Address
Mandatory field.
Specify the virtual Local Endpoint IP Address of this OpenVPN router.
Value Range: The IP format is 10.8.0.x, the range of x is 1 - 254.
Note
–
Local Endpoint IP Address will be available only when
Static Key is chosen in Authorization Mode.
Remote
Endpoint IP
Address
Mandatory field.
Specify the virtual Remote Endpoint IP Address of the peer OpenVPN
router.
Value Range: The IP format is 10.8.0.x, the range of x is 1 - 254.
Note
–
Remote Endpoint IP Address will be available only
when Static Key is chosen in Authorization Mode.
Static Key
Mandatory field.
Specify the Static Key.
Note
–
Static Key will be available only when Static Key is chosen
in Authorization Mode.
Server Virtual
IP
Mandatory field.
Specify the Server Virtual IP.
Value Range: The IP format is 10.y.0.0, the range of y is 1 - 254.
Note
–
Server Virtual IP will be available only when TLS is chosen
in Authorization Mode.
To Next Page
