NetCommWireless NTC-400 Series User Manual

NTC-400 Series
229 of 361
© NetComm Wireless 2018
Item Notes Description
Delete Button Click  Select for the User Account that you want to permanently delete
and then click the Delete button.
Enable Button Click the Edit button to select Tunnel  Enable in the L2TP Client
Configuration window .
Note that you can uncheck  Enable rather than permanently Delete, this
will allow you to retain the user details while disabling its access to the
L2TP client.
Edit Button Click the Edit button to make changes to the client in the L2TP Client
Configuration window
.
Select Checkbox Click  Select on one or more Client descriptions and then click the Delete
button to permanently remove them from the list..
Table 160 – L2TP Client List & Status
When Add or Edit button is applied, the L2TP Client Configuration window will appear:
Figure 266 – L2TP Client Configuration
Item Notes Description
Tunnel Name Mandatory field.
1 - 32 characters
Add a meaningful name.
Interface Mandatory field. WAN-1 is available only when WAN-1 interface is enabled).
The same applies to other WAN interfaces (i.e. WAN-2).
Operation
mode
Mandatory field. There are three available operation modes: Always on, Failover, Load
Balance
Failover/ Always on : Define whether the PPTP client is a failover tunnel
function or an always on tunnel.
Note – If this PPTP is a failover tunnelling, you will need to select
a primary IPSec tunnel from which to failover to.
Load Balance – Define whether the PPTP tunnel connection will take part
in load balance function of the gateway. You will not need to select which
