Setting up Compax3
192-121102 N04 June 2008 149
4.3.5. Setup mode
The setup mode is used for moving an axis independent of the system control
The following functions are possible:
Machine reference run
Jog+ / Jog-
Activation / deactivation of the motor holding brake.
Acknowledging errors
Defining and activating a test movement
Activating the digital outputs.
Activating the setup mode
By activating the setup mode, the the control program (IEC Program) is
deactivated; the system function of the device is no longer available.
Access via an interface (RS232/RS485, Profibus, CANopen,...) and via
digital inputs is deactivated.
Attention! The safety functions are not always guaranteed during
the setup mode!
In the Commissioning window (left at the bottom) the commissioning mode is
activated.
Then parameterize the desired test movement in the Parameter window.
You can accept changed configuration settings into the current project.
Now energize drive in the commissioning window and start the test movement.
Caution! Safeguard the travel range before energizing!
Deactivating the setup mode
If the setup mode is left, the drive is deactivated and the the control
program (IEC Program) is re-activated.
The parameters of the setup window are saved with the project and are loaded
into Compax3 if the setup mode is activated (see below).
Note:
